Humidifier Digital Ultrasonic Atomizer 24V Ultrasonic Atomizing Module

Name: Humidifier Digital Ultrasonic Atomizer 24V Ultrasonic Atomizing Module
Brand: AUDIOWELL
Price: 1 USD

Brand Name : AUDIOWELL

Model Number : UM0108-003

Place of Origin : China

MOQ : 3000

Payment Terms : T/T

Delivery Time : 30 works days

Transducer frequency : 1.7±0.05MHz

Mist volume : 360mL/h±20%

Model : UM0108-003

Contact Now

Ultrasonic Atomizer For Humidifier 24V Ultrasonic Atomizing Module

The Ultrasonic Digital Atomizer is an intelligent ultrasonic atomization device which integrates the atomizing transducer and circuit board. Compared to the traditional atomizer which has separate circuit and transducer, it features compact size, low power consumption and low heat. Unlike the traditional one with analog signal control, it is controlled by digital signal, thereby facilitating the development of extensional functions such as APP control, bluetooth connection, controlled lighting, etc to intelligentize the whole device.

Features

- Integrated transducer+circuit design and compact size
- High conversion efficiency, low power consumption and heat
- Built-in water level detection for anti-dry protection
- Digital signal control, easy extension development

Specifications

Model	UM0108-003
24V power supply	DC: 24±1.2V, 750mA
5V power supply	DC: 5V-5.5V, 30mA
Transducer frequency	1.7±0.05MHz
Max operating current	0.65±0.07A
Mist volume	360mL/h±20%

Applications

- Humidifiers
- Air conditioning humidification
- Medical atomizer
- Electronic fireplace
